| PART | UNIT | DIMENSIONS |
| ØD | mm | 62,00 |
| Ød | mm | 30,00 |
| B | mm | 20,00 |
| H | mm | 37,50 |
| h | mm | 30,50 |
| A | mm | 2,50 |
| D1 | mm | 42,00 |
| S | mm | 20,00 |
| R | mm | 3,00 |
| C | kN | 39,00 |
| Co | kN | 65,20 |
| Ca | kN | 14,40 |
| Coa | kN | 21,00 |
5.2890
See more product details
*Esta imagen se proporciona exclusivamente con fines ilustrativos. Es importante tener en cuenta que, siendo una representación genérica, puede presentar diferencias en algunos acabados con el producto final que reciba.
This series of bearings has the following characteristics:
| PART | UNIT | DIMENSIONS |
| ØD | mm | 62,00 |
| Ød | mm | 30,00 |
| B | mm | 20,00 |
| H | mm | 37,50 |
| h | mm | 30,50 |
| A | mm | 2,50 |
| D1 | mm | 42,00 |
| S | mm | 20,00 |
| R | mm | 3,00 |
| C | kN | 39,00 |
| Co | kN | 65,20 |
| Ca | kN | 14,40 |
| Coa | kN | 21,00 |
Outer ring and axial little roll are manufactured in case-hardening steel type 20CrMnTi. This kind of steel guarantees a very good resistance to stress, and assures a very good resistance against crashes. The surface hardness can reach 60-2 HRC for both of them.
Inner ring and pin are manufactured in core-hardened 100 Cr6 steel. The total-hardening steel guarantees high resistance to wear and stress; both of them reach 60-2 HRC hardness value.
The central pivot is made in low carbon C20/C45 steel, which guarantees high resistance and is highly suitable for welding.
The lateral thrust cover is made in case-hardening steel as well.
Combination of the ZZ (metallic) and RS (rubber) sealing systems. ZRS seals offer a more hermetic bearing, ensuring that the active parts of the bearing (rollers, cages and raceways) remain clean and well lubricated, preventing outer agents, such as dust, wet and mill scale, to enter the inner part of the bearing. At the same time it prevents the leakage of lubrication grease. The AT series prepared for high temperatures have ZZ seals.
Lubricants are general purpose industrial greases based on a new lithium hydroxystearate soap thickener fortified with anti-oxidant, anti-wear and anti-rust additives.
Lubricants may be used under a wide range of operating conditions:
| Weight | 0,525 kg |
|---|
